Bearings   No.	Dimensions mm											£¨KN£©Load ratings		a¡£ ¡Ö	Weight ¡Ö
	C1	d	B	d2  max	d3	h1	L3  min	L4  max	L5  max	d5  max	S	Dynamic	Static
PHS 5	6	5	8	16	M5?.8	27	14	35	4	11	9	3.3	4.1	13	0.016
PHS 6	6.75	6	9	18	M6?	30	14	39	5	13	11	4.3	5.3	13	0.026
PHS 8	9	8	12	22	M8?.25	36	17	47	5	16	14	6.8	8.5	14	0.044
PHS 10	10.5	10	14	26	M10?.5	43	21	56	6.5	19	17	10	11	14	0.072
PHS 12	12	12	16	30	M12?.75	50	24	65	6.5	22	19	13	14	13	0.108
PHS 14	13.5	14	19	34	M14?	57	27	74	8	25	22	17	20	16	0.161
PHS 16	15	16	21	38	M16?	64	33	83	8	27	22	21	25	15	0.225
PHS 18	16.5	18	23	42	M18?.5	71	36	92	10	31	27	26	30	15	0.295
PHS 20	18	20	25	46	M20?.5	77	40	100	10	34	30	31	35	15	0.382
PHS 22	20	22	28	50	M22?.5	84	43	109	12	37	32	38	43	15	0.488
PHS 25	22	25	31	60	M24?	94	48	124	12	42	36	47	65	15	0.749
PHS 28	25	28	35	66	M27?	103	53	136	12	46	41	59	77	15	0.949
PHS 30	25	30	37	70	M30?	110	56	145	15	50	41	63	86	17	1.13

Note: When the trread is left-hand,mark it by: PHS...L

2.Inlaid Liner Rod Ends with Mail Thread.

Bearings No.	Dimensions mm										(KN£©Load ratings		a¡£ ¡Ö	Weight ¡ÖKg
	d	B	r1	c1	d1	d2	d3	h	L1	L2	Dynamic	Static
POS 5	5	8	0.3	6	7.7	16	M5?.8	33	20	41	3.3	3.9	13	0.016
POS 6	6	9	0.3	6.75	9	18	M6?	36	22	45	4.3	5.3	13	0.026
POS 8	8	12	0.3	9	10.4	22	M8?.25	42	25	53	6.8	8.5	14	0.044
POS 10	10	14	0.6	10.5	12.9	26	M10?.5	48	29	61	10	11	14	0.072
POS 12	12	16	0.6	12	15.4	30	M12?.75	54	33	69	13	14	13	0.108
POS 14	14	19	0.6	13.5	16.9	34	M14?	60	36	77	17	20	16	0.161
POS 16	16	21	0.6	15	19.4	38	M16?	66	40	85	21	25	15	0.225
POS 18	18	23	0.6	16.5	21.9	42	M18?.5	72	44	93	26	30	15	0.295
POS 20	20	25	0.6	18	24.4	46	M20?.5	78	47	101	31	35	15	0.382
POS 22	22	28	0.6	20	25.8	50	M22?.5	84	51	109	38	43	15	0.488
POS 25	25	31	0.6	22	29.6	60	M24?	94	57	124	47	65	15	0.749
POS 28	28	35	0.6	25	32.3	66	M27?	103	62	136	59	77	15	0.949
POS 30	30	37	0.6	25	34.8	70	M30?	110	66	145	63	86	17	1.13

Note: When the trread is left-hand,mark it by: POS...L

3. Maintenance-Free  Rod Ends with Femail Thread

Bearing No.	Dimensions mm									a¡£ ¡Ö	Max   Load   capacity	Weight   ¡ÖKg	old Desogntion
	d1	M	d2	d4	b1	b2	l1	l2	d3
PHSA 6	6	M6?	20	13	9	6.75	30	12	10	13	7.20	0.027	SI6T/K
PHSA 8	8	M8?.25	24	16	12	9	36	16	12.5	13	11.60	0.046	SI8T/K
PHSA 10	10	M10?.5	28	19	14	10.5	43	20	15	13	14.50	0.076	SI10T/K
PHSA 12	12	M12?.75	32	22	16	12	50	22	17.5	13	17.00	0.115	SI12T/K
PHSA 14	14	M14?	36	25	19	13.5	57	25	20	13	24.00	0.170	SI14T/K
PHSA 16	16	M16?	42	27	21	15	64	28	22	13	28.5	0.230	SI16T/K
PHSA 18	18	M18?.2	46	31	23	16.5	71	32	25	13	35.00	0.320	SI18T/K
PHSA 20	20	M20?.5	50	34	25	18	77	33	27.5	13	40.00	0.42	SI20T/K
PHSA 22	22	M22?.5	54	37	28	20	84	37	30	13	52.00	0.54	SI22T/K
PHSA 25	25	M25?	60	42	31	22	94	42	33.5	13	60.00	0.75	SI25T/K
PHSA 30	30	M30?	70	50	37	25	110	51	40	13	81.00	1.30	SI30T/K

Note: when the thread is left-hand, mark it by: PHSAL(SIL...T/K )

4.Maintenance-Free  Rod Ends with Femail Thread

Bearings No.	Dimensions mm								a¡£ ¡Ö	Max   Load   capacity	Weight ¡ÖKg	Old Desogntion
	M	d1	d2	b1	b2	l1	l2	l3
POSA 6	M6?/font>1	6	20	9	6.75	30	22	10	13	4.40	0.021	SA6T/K
POSA 8	M8?/font>1.25	8	24	12	9	36	25	11.7	13	8.00	0.034	SA8T/K
POSA 10	M10?/font>1.5	10	28	14	10.5	43	29	13.5	13	12.90	0.058	SA10T/K
POSA 12	M12?/font>1.75	12	32	16	12	50	33	15	13	17.00	0.092	SA12T/K
POSA 14	M14?/font>2	14	36	19	13.5	57	36	16.5	13	24.00	0.153	SA14T/K
POSA 16	M16?/font>2	16	42	21	15	64	40	19.5	13	28.5	0.205	SA16T/K
POSA 18	M18?/font>1.2	18	46	23	16.5	71	44	21.5	13	35.00	0.280	SA18T/K
POSA 2	M20?/font>1.5	20	50	25	18	77	47	23	13	40.00	0.370	SA20T/K
POSA 22	M22?/font>1.5	22	54	28	20	84	51	25	13	52.00	0.475	SA22T/K
POSA 25	M25?/font>2	25	60	31	22	94	57	28	13	60.00	0.650	SA25T/K
POSA 30	M30?/font>2	30	70	37	25	110	66	32.5	13	81.00	1.070	SA30T/K

Note: when the thread is left-hand, mark it by: POSAL(  SAL...T/K )
